Features
Transparent | Modular | Lightweight | Self cooling | Protection IP67
Exclusive patent | Multiple density options | Clasp splicing | Wire fixation | Roll and bag transportation
It is commonly used for making lamps for solid wall, steel structure, glass curtain wall plane or curved display screen of large indoor and outdoor buildings; Cultural tourism promotion, commercial advertising, city business card promotion and other large, medium and large display media.
Technical parameters
| Item |
XH-HXH30-1 |
XH-HXH30-3 |
XH-HXH30-4 |
| Product Model |
XH-HXH30-1 |
XH-HXH30-3 |
XH-HXH30-4 |
| Operating Voltage |
DC5V |
DC12V |
DC12V |
| Light Source Color |
RGB/RGB+W |
RGB/RGBW |
RGB+W |
| Power per Pixel |
0.3/0.4W |
0.75W |
1W |
| Control Protocol |
DMX512 |
DMX512 |
DMX512 |
| Pixel Density |
100pcs |
100pcs |
100pcs |
| Pixel Pitch |
100mm |
100mm |
100mm |
| Max Power |
30/40W |
30/100W |
80/100W |
| Screen Weight |
2.7kg |
2.7kg |
2.7kg |
| Housing Material |
Flame-retardant PC bracket + silicone |
Safety Protection |
|
| Beam Angle |
160° |
Ingress Protection: IP67 |
Impact Resistance: IK10 |
| Operating Temperature |
-20℃ ~ +60℃ |
Flame Class: V-0 |
Salt Spray Test: Salt Resistance |
| Average Lifespan |
＞30000h |
Electrical Safety Class: Class III |
|
